- 1 x Emergency Stop Device Station
- 1 x 16ft RJ12 Cable
- 1 x 4ft RJ12 Cable
- 1 x RJ12 T-Splitter
TrolMaster Carbon-X DSE-1 CO2 Emergency Stop Station
$171.04 CAD
starting from 0% interest financing from
/mo.
- Supports 10A output current to handle most commercial solenoid valves
- Plug and play design with standard RJ12 connections for easy system integration
- Rated for operational temperatures between 32 and 122 degrees Fahrenheit
- 3-year warranty covering mechanical and electronic components under normal operating conditions
- View More Details
Earn 171 points for shopping and get $1.71 off your next order. Join Harvest Club for free.
Free Shipping On Most Items
To the Provinces*
Transparent Pricing
Backed w/ price match guarantee
Secure Checkout
SSL encrypted payments
VOLUME PRICING
Commercial & Bulk Purchasing
We support operations & licensed facilities with volume pricing, dedicated account managers, and custom equipment consultation.
Who This Is For
- You are integrating a high-pressure gas system because you need to automate plant growth rates without manual monitoring
- You are building a fail-safe climate system because you need an immediate shutdown mechanism to protect your facility staff
What We Found
- This device simplifies your safety cabling by using standard RJ12 connections that snap into the existing system
- We appreciate that it acts as a true circuit breaker for your solenoid valves, which removes the guesswork in a leak event
What Users Say
- Growers who added this to their environment report that they have total peace of mind during overnight system operation
- Users who installed this emergency station say it passed their facility inspection because it meets safety requirements
TrolMaster Carbon-X DSE-1 CO2 Emergency Stop Station
Safety is paramount in any high-CO2 environment. The TrolMaster Carbon-X DSE-1 serves as a critical fail-safe for your facility, designed to shut down your CO2 supply immediately when levels reach a dangerous threshold. By integrating this device into your TrolMaster Carbon-X system, you ensure that equipment malfunctions or leaks don't compromise the safety of your staff or your crop.
Operation is seamless and reliable. During standard operation, the DSE-1 provides consistent power to your CO2 solenoid valves. However, the moment the TrolMaster Carbon-X CDA-1 CO2 Alarm System detects levels exceeding the programmed safety limit—often via the Carbon-X MBS-K30 CO2 Sensor—the DSE-1 automatically disables the system. This plug-and-play solution is an essential component for any grower looking to maintain a secure and professional cultivation environment.
What's Included
Features
🛑
Automated Shutdown
The DSE-1 deactivates CO2 solenoid valves instantly when high levels are detected.
🔌
Plug and Play
Ready to use out of the box with standard RJ12 connections, compatible with the TrolMaster ECS-1 cable kit for easy expansion.
🤝
System Synergy
Designed to work in perfect tandem with the MBS-K30 sensor and the Carbon-X monitoring ecosystem.
⚡
High Capacity
Supports a 10A output current to handle most commercial CO2 solenoid valves.
Specifications
| Specification | Value |
|---|---|
| Input Voltage | 100~240 VAC, 50/60Hz |
| Output Current | 10A |
| Output Voltage | 100~240 VAC, 50/60Hz |
| Working Environments | Temperature 32-122°F, Humidity <= 90% |
| Package Dimensions | 85mm(L) x 80mm(W) x 90mm(H) |
| G.W. per pack | 0.34kgs |
Support & Manuals
Warranty
TrolMaster only uses high quality components. Under normal operating conditions, the mechanical and electronic components are covered by a three-year warranty from the original date of purchase. Components that are excluded from warranty are components that have failed due to abnormal usage.
FAQs
What is the primary function of the Carbon-X DSE-1?
The DSE-1 acts as an emergency stop station that automatically cuts power to your CO2 solenoid valves if the Carbon-X system detects CO2 levels that exceed safety thresholds.
Does this require a separate controller?
Yes, the DSE-1 is designed to work specifically with the TrolMaster Carbon-X CDA-1 CO2 Alarm System.
What is the maximum current load for the DSE-1?
The device supports a maximum output current of 10A, making it suitable for most standard CO2 injection equipment.
Are the connection cables included?
Yes, each unit comes with one 16ft RJ12 cable, one 4ft RJ12 cable, and an RJ12 T-Splitter for easy installation.
Is the DSE-1 difficult to set up?
No, it features a plug-and-play design that allows for quick integration into your existing TrolMaster environment using standard RJ12 cabling without complex wiring.
